SF Romane steam locomotives

All dimensions metric: lengths in mm, areas in m², weights in metric tons, pressures in atmospheres.

Class Axle
Arr. Dr.
Dia. Cylinders
Dia. x Str. BP Ad.
Wt. EW
WO Grate
Area Evap
Surf. Sup.
Surf Remarks

1 1A1 1805 380x510   7 9 24 1.2 73 none Canada Works 1863

25 1A1 1680 360x510   6 8 20 1.0 65 none Sharp Stewart 1858

41 1A1 1675 355x560   4 7 22 0.8 72 none Stephenson 1844

51 2A 1975 380x610   7 14 26 1.0 86 none Stephenson 1847

61 2'B 1525 355x560   6 16 22 0.9 71 none Norris 1846

71 1B 1370 355x430   6 16 22 1.0 78 none FS Napoli 1855

81 1B 1535 355x510   7 15 20 1.1 70 none Macry Henry 1861

91 1B 1675 355x560   6 16 22 0.9 74 none Stephenson 1846

101 1B 1680 380x610   6 19 26 1.0 84 none Jones Potts 1846

111 1B 1650 380x555   6 17 25 1.0 78 none Haigh 1846

121 1B 1515 380x610   6 18 25 1.0 80 none Stephenson 1845

131 1B 1515 380x610   7 17 25 1.0 85 none Stephenson 1849

141 B1 1525 405x610   7 21 26 1.2 83 none Ansaldo 1859

151 B1 1520 380x610   7 19 26 1.1 82 none Ansaldo 1861

161 1B 1520 380x610   7 18 25 1.0 84 none Stephenson 1862

167 1B 1520 405x610   8 18 26 1.0 79 none Siena 1865

171 1B 1655 405x510   7 17 26 1.2 76 none Canada Works 1864

181 1B 1655 430x635   8 20 29 1.1 94 none Stephenson 1863

191 1B 1655 430x560   6 19 27 1.2 100 none Esslingen 1863

201 1B 1695 430x560   8 22 30 1.3 110 none

301 1B 1620 420x600   8 21 31 1.3 115 none

381 1B 1575 420x560   7 21 29 1.1 105 none Cail 1858

391 1Bt 1560 280x560   8 26 33 1.1 67 none Sharp Stewart 1856

401 1B 1475 400x360   8 25 37 1.6 122 none Sigl 1871

411 1B 1350 400x510   7 19 27 1.1 99 none Escher Wyss 1861

421 1B 1805 380x610   6 17 27 1.0 69 none Stephenson 1868

431 1B 1775 420x560   7 20 29 1.1 105 none Cail 1856

441 1B 1910 380x560   7 17 28 1.1 89 none Escher Wyss 1862

451 1B 1790 380x610   8 18 27 1.0 97 none Sharp Stewart 1862

461 1B 1910 430x610   8 21 33 1.5 90 none Stephenson 1872

495 2'B 1850 430x610 10 26 41 2.1 92 none Borsig 1881

501 C 1430 380x610   8 25 25 1.0 82 none Stephenson 1843

531 C 1370 440x600   7 29 29 1.1 105 none Cail 1858

541 C 1450 420x600   8 33 33 1.3 112 none

551 C 1350 430x585   8 27 27 1.1 97 none

571 C 1350 430x595   8 31 31 1.3 94 none Sigl 1875

601 C 1280 450x650   8 33 33 1.4 124 none

1001 Bt 680 280x440   6 18 18 0.5 31 none Anjubault 1863

1002 1At 1530 235x380   6 10 15 0.5 36 none Briggs Adams 1860

Class	Axle Arr.	Dr. Dia.	Cylinders Dia. x Str.	BP	Ad. Wt.	EW WO	Grate Area	Evap Surf.	Sup. Surf	Remarks
1	1A1	1805	380x510	7	9	24	1.2	73	none	Canada Works 1863
25	1A1	1680	360x510	6	8	20	1.0	65	none	Sharp Stewart 1858
41	1A1	1675	355x560	4	7	22	0.8	72	none	Stephenson 1844
51	2A	1975	380x610	7	14	26	1.0	86	none	Stephenson 1847
61	2'B	1525	355x560	6	16	22	0.9	71	none	Norris 1846
71	1B	1370	355x430	6	16	22	1.0	78	none	FS Napoli 1855
81	1B	1535	355x510	7	15	20	1.1	70	none	Macry Henry 1861
91	1B	1675	355x560	6	16	22	0.9	74	none	Stephenson 1846
101	1B	1680	380x610	6	19	26	1.0	84	none	Jones Potts 1846
111	1B	1650	380x555	6	17	25	1.0	78	none	Haigh 1846
121	1B	1515	380x610	6	18	25	1.0	80	none	Stephenson 1845
131	1B	1515	380x610	7	17	25	1.0	85	none	Stephenson 1849
141	B1	1525	405x610	7	21	26	1.2	83	none	Ansaldo 1859
151	B1	1520	380x610	7	19	26	1.1	82	none	Ansaldo 1861
161	1B	1520	380x610	7	18	25	1.0	84	none	Stephenson 1862
167	1B	1520	405x610	8	18	26	1.0	79	none	Siena 1865
171	1B	1655	405x510	7	17	26	1.2	76	none	Canada Works 1864
181	1B	1655	430x635	8	20	29	1.1	94	none	Stephenson 1863
191	1B	1655	430x560	6	19	27	1.2	100	none	Esslingen 1863
201	1B	1695	430x560	8	22	30	1.3	110	none
301	1B	1620	420x600	8	21	31	1.3	115	none
381	1B	1575	420x560	7	21	29	1.1	105	none	Cail 1858
391	1Bt	1560	280x560	8	26	33	1.1	67	none	Sharp Stewart 1856
401	1B	1475	400x360	8	25	37	1.6	122	none	Sigl 1871
411	1B	1350	400x510	7	19	27	1.1	99	none	Escher Wyss 1861
421	1B	1805	380x610	6	17	27	1.0	69	none	Stephenson 1868
431	1B	1775	420x560	7	20	29	1.1	105	none	Cail 1856
441	1B	1910	380x560	7	17	28	1.1	89	none	Escher Wyss 1862
451	1B	1790	380x610	8	18	27	1.0	97	none	Sharp Stewart 1862
461	1B	1910	430x610	8	21	33	1.5	90	none	Stephenson 1872
495	2'B	1850	430x610	10	26	41	2.1	92	none	Borsig 1881
501	C	1430	380x610	8	25	25	1.0	82	none	Stephenson 1843
531	C	1370	440x600	7	29	29	1.1	105	none	Cail 1858
541	C	1450	420x600	8	33	33	1.3	112	none
551	C	1350	430x585	8	27	27	1.1	97	none
571	C	1350	430x595	8	31	31	1.3	94	none	Sigl 1875
601	C	1280	450x650	8	33	33	1.4	124	none
1001	Bt	680	280x440	6	18	18	0.5	31	none	Anjubault 1863
1002	1At	1530	235x380	6	10	15	0.5	36	none	Briggs Adams 1860
